Instrumentation

Our Laboratories

The department of chemistry "Giacomo Ciamician" in located in via Piero Gobetti, 85 (40129) Bologna (BO). The laboratories are six divided in thematics and research field. Two of them are dedicated to organic, ultra-high vacuum and not-organic preparations then, ECL, catalysis, electrochemical characterization (potentiostat) and electrochemical in situ techniques (AFM, SECM). The following pictures reports the instrumentation we own.

water-based preparative lab
organic-based preparative lab
ECL lab
Electrochemical characterization lab
Catalysis Lab

Potentiostat Biologic SP-300

Argon line to be able to work under dry conditions.



ECL lab:

on the top of the dark box: CCD Hamamatsu EM9100-13 512x512          10x NA03WD 17.5mm

inside the dark box:               Nikon Eclipse LV100                                           4x

                                                       Autolab PGSTAT30

                                                       Stage motorizzato Marzhauser                       20x NA04WD 19mm



ECL Lab:

Inverted microscope Nikon ECLIPSE Ti2

Unparalleled 25 mm field of view (FOV), CMOS camera, drift-free platform

Oil objectives: 40 x and 100 x

ECL lab:

ACTON Research model 181                            100x NA08WD 4.5mm

Amplifier

and inside the dark box: PMT Hamamatsu R4220P                                 40x NA06WD 2.8-3.6mm



ECL lab:

Microfluidic cell

Electrocatalysis lab:

from left to right:  H2 generator

                                     SRI 8610C

                                     Gas-Chromatograph (SRI Instruments)

                                     Mass Flow Control

                                     Peristalic Pump MasterFlex L/S Favs Model 77200-50

                                     MICRO FLOW CELL  MFC30010ElectroCell (EC)

Ionic Chromatograph Metrohm

Electrocatalysis Lab:

Ionic Cromatograph (IC) equipped with autosampler

  • Model 930 Compact IC Flex Methrom
  • Column: Metrosep A Supp 19-150

Electrocatalysis lab:

SP-300 Potentiostat Biologic

ECL lab:

SP-300 Potentiostat Biologic

SP-150e  Potentiostat Biologic

Atomic Force Microscopy Veeco III Nanoscope 3D

High vacuum lines:

Edwards Turbomolecular pump and Pfeiffer Turbomolecular pump



Scanning Electrochemical Surface Microscopy (SECM) CH Instruments

Spectrophotometer Varian Cary 5  UV-Vis-NIR used for photoelectrochemistry
